FT-0610487 CAS:725-12-2 chemical structure

2,5-DIPHENYL-1,3,4-OXADIAZOLE

Name: 2,5-DIPHENYL-1,3,4-OXADIAZOLE
Rating: 4.5 (11 reviews)

Catalog No: FT-0610487

CAS No: 725-12-2

Molecular Formula: 222.24
Formula Weight: C14H10N2O
Inchl Key: DCJKUXYSYJBBRD-UHFFFAOYSA-N
Inchl: InChI=1S/C14H10N2O/c1-3-7-11(8-4-1)13-15-16-14(17-13)12-9-5-2-6-10-12/h1-10H

Assay	Pack	Price	Stock
98%	1g	N/A	N/A
98%	5g	N/A	N/A
98%	Bulk Quantity	N/A	N/A

Product_Name:	2,5-Diphenyl-1,3,4-oxadiazole
Flash_Point:	231°C/13mm
Melting_Point:	138-140 °C(lit.)
FW:	222.24200
Density:	1.174 g/cm3
CAS:	725-12-2
Bolling_Point:	231 °C13 mm Hg(lit.)
MF:	C14H10N2O

Molecular_Structure:	['1 . Molar refractive index 6391 ', '2 . Molar volume （m3/mol）1892 ', '3 . Parachor （902K）4962 ', '4 . Surface tension 472 ', '5 . Dielectric constant ', '6 偶极距（10 -24cm 3） ', '7 . Polarizability 2533']
Flash_Point:	231°C/13mm
Refractive_Index:	1.59
FW:	222.24200
Density:	1.174 g/cm3
Bolling_Point:	231 °C13 mm Hg(lit.)
Computational_Chemistry:	['1. XlogP :31 ', '2. Hydrogen Bond Donor Count :0 ', '3. Hydrogen Bond Acceptor Count :3 ', '4. Rotatable Bond Count :2 ', '5. Isotope Atom Count :N/A ', '6. TPSA 389 ', '7. Heavy Atom Count :17 ', '8. Topological Polar Surface Area :0 ', '9. Complexity :210 ', '10. Isotope Atom Count :0 ', '11. Defined Atom Stereocenter Count :0 ', '12. Undefined Atom Stereocenter Count :0 ', '13. Defined Bond Stereocenter Count :0 ', '14. Undefined Bond Stereocenter Count :0 ', '15. Covalently-Bonded Unit Count :1']
LogP:	3.40360
Melting_Point:	138-140 °C(lit.)
PSA:	38.92000
MF:	C14H10N2O
More_Info:	['1 . Appearance White Solid ', '2 . Density（g/mL,25/4℃）Unknow ', '3 . Relative vapor density（g/mL,Atmosphere =1）Unknow ', '4 . Melting point（ºC）138-140 ', '5 . Boiling point（ºC,13mmHg）231 ', '6 . Boiling point（ºC,52kPa）Unknow ', '7 . Refractive indexUnknow ', '8 . Flash point（ºC13mmHg）231 ', '9 . Specific rotation（º）Unknow ', '10 . Spontaneous ignition point or ignition temperature（ºC）Unknow ', '11 . Vapor pressure（kPa,25ºC）Unknow ', '12 . Saturated vapor pressure（kPa,60ºC）Unknow ', '13 . Combustion heat（KJ/mol）Unknow ', '14 . Critical temperature（ºC）Unknow ', '15 . Critical pressure（KPa）Unknow ', '16 . Oil-water（Octanol /Water ）Logarithmic Value of Distribution Coefficient Unknow ', '17 . Upper limit of explosion（%,V/V）Unknow ', '18 . Lower limit of explosion（%,V/V）Unknow ', '19 . Solubility Insoluble in Water ']
Exact_Mass:	222.07900
